Panasonic SCHTB880EBK Bluetooth, 5.1Ch, Home Cinema Sound Bar 500W Output

AUDIO SYSTEM

• Output Channel 5.1ch
• Power Output - Home Cinema Mode (RMS) Total Power 500W
• Front 50W/ch (1kHz, 6ohms, 10% THD)
• Centre 50W (1kHz, 6ohms, 10% THD)
• Surround 50W/ch (1kHz, 6ohms, 10% THD)
• Subwoofer 250W (100Hz, 8ohms, 10% THD)
• Dolby® Digital yes
• Dolby® Pro Logic® II/ Dolby® Virtual Speaker yes
• DTS™ Digital Surround yes

• FULL HD 3D Compatible yes
• 1080p Output (x.v.Color, Deep Color) yes

• LincsD-Amp yes (2nd generation)
• Clear-mode Dialog yes
• Dialog Level Control yes
• Multi-angle Speaker Layout yes
• aptX®Low Latency yes
• H.Bass yes
• Down Firing Subwoofer yes
• Up to 7.1ch Linear PCM Input via HDMI yes

• 4K Signal Pass Through yes
• Wireless Subwoofer yes
• Auto Gain Control yes
• ARC (Audio Return Channel) yes*1
• IR Blaster Included yes
• VIERA Link™ (HDAVI Control 5) yes
• Wall-Mountable Speaker yes

• Bluetooth® Wireless Technology yes
• Panasonic Music Streaming App yes*2
• NFC (One-Touch Connection) yes*3

• Configuration 2-way 2 speakers, Bass-reflex
• Speaker Unit [Approx.] Woofer: 6.5 cm Cone Type/Tweeter: 2.5 cm Semi-dome Type

• Configuration 1-way 1 speaker, Bass-reflex
• Speaker Unit [Approx.] Full Range: 6.5 cm Cone Type

• Configuration 1-way 1 speaker, Bass-reflex
• Speaker Unit [Approx.] Full Range: 6.5 cm Cone Type

• Configuration 1-way 1 speaker, Bass-reflex
• Speaker Unit [Approx.] Woofer: 16 cm Cone Type
• Dimensions (W x H x D) [Approx.] 180 x 408 x 306 mm
• Weight [Approx.] 5.4 kg

• HDMI Output yes (TV)
• HDMI Input yes (2) (BD/ DVD, AUX)
• Digital Audio Input yes (TV)

• Power Supply AC 220-240V, 50Hz
• Power Consumption - Total [Approx.] Normal Use [Approx.] 33W
• Standby (Bluetooth standby off) [Approx.] 0.49W*4
• Power Consumption - Subwoofer [Approx.] Normal Use [Approx.] 46W
• Standby (Power switch off) [Approx.] 0.2W*5
• Suitable TV Sizes 50"

• Weight [Approx.] 3.1 kg

NOTE *1 ARC compatible TV is required.

NOTE *2 App is available on the App Store. App is available on Google Play™.

NOTE Specifications are subject to change without notice.
